Valve Body 3/4 in, 2W, Zone, NPT, BR, 2.5 cv, 40 PSI; Act (AG13B020): Elec, 2Pos, SR, NC, 110-120 VAC, App, N1
$124.66
Available on backorder
Give us a call for availability
WARNING: This product can expose you to chemicals including lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov Valve Assembly:
Product Alert: Not for use with steam
Assembly Components:
Product Alert: Not for use with steam
| Manufacturer Name | |
|---|---|
| Valve Type | ZONE |
| Actuator Type | ELECTRIC |
| Auxiliary Switch | NO |
| Close-Off Pressure | 40 psi |
| Valve Configuration | 2-WAY |
| Connection Type | NPT |
| Control Signal | 2-POSITION (ON/OFF) |
| Flow Characteristic | Quick open |
| Flow Coefficient | 2.50 cv |
| Fail Safe Position | Normally Closed |
| Fail Safe Type | Spring Return |
| Body Material | Forged Brass |
| Mechanical Movement | ROTARY |
| Media Compatability | Glycol 25%, Glycol 30%, Glycol 50%, Water |
| Actuator Override | Automatic Reset |
| Pipe Size | 3/4" |
| Power Consumption | 7.50 VA |
| Voltage | 110 VAC##115 VAC##120 VAC |
| Pressure Allowable Static | 400 psi |
| Pressure Class | 400 ANSI |
| Valve Product Range | Erie PopTop |
| Temperature Range | 32° to 200° F |
| Temperature Range Fluid | 32° to 200° F |
